ASRock H310M-ITX/ac Desktop Motherboard - Intel H310 Chipset - Socket H4 LGA-1151 - Mini ITX

  • Part: 1274767
  • Model: H310M-ITX/AC
$178.13

Availability

Out of Stock

  • General Information
    • Manufacturer
    • ASRock, Inc
    • Manufacturer Website Address
    • http://www.asrock.com
    • Brand Name
    • ASRock
    • Product Type
    • Desktop Motherboard

  • Supports 8th Generation Intel® Core™ Processors (Socket 1151)
  • Supports DDR4 2666
  • 1 PCIe 3.0 x16
  • Graphics Output Options: HDMI, DVI-I, DisplayPort
  • 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps
  • 4 SATA3, 1 M.2 (PCIe Gen2 x4 & SATA3)
  • 4 USB 3.1 Gen1 (2 Front, 2 Rear)
  • Intel® Gigabit LAN
  • Intel® 802.11ac WiFi + BT 4.2

PCIe Gen2 x4 M.2

The PCIe Gen2 x4 interface pushes data transfer speeds up to 20Gb/s. In addition, it also supports SATA 3 6Gb/s M.2 modules, and is compatible with ASRock's U.2 Kit for installing some U.2 SSDs.

Intel® LAN

Intel® LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users!

Dual Band 802.11ac WiFi

No one has time for weak WiFi signals and sluggish internet! That's why this motherboard comes with a 802.11ac WiFi (2.4G / 5G WiFi) module which supports wireless networks and Bluetooth v4.0.

Premium 60A Power Choke

Compared to traditional chokes, ASRock's premium 60A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.

Dual-Stack MOSFET (DSM)

Dual-Stack MOSFET (DSM) is another innovative MOSFETs design by ASRock. The silicon die area is increased by stacking two dies into one MOSFET. The larger the die area, the lower Rds(on). Compared to traditional discrete MOSFET, DSM with larger die area provides extreme lower Rds(on) 1.2 mΩ, so the power supply for the CPU Vcore is more efficient.

Sapphire Black PCB

Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.

High Density Glass Fabric PCB

High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.

3 Graphics Outputs

Complete with all three types of most used connectors! Packed with a DisplayPort + DVI-I + HDMI combo.

Digi Power

Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.

ELNA Audio Caps

Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream and entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3uA. This is the key to reduce noise level significantly and satisfy even the pickiest audiophiles.

A-Tuning

A-Tuning is ASRock's multi purpose software suite with a new interface, more new features and improved utilities.

Full Spike Protection

Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard's components from being damaged by these unexpected voltage spikes.

  • Processor & Chipset
    • Chipset Manufacturer
    • Intel
    • Chipset Model
    • H310
    • Total Processor Supported
    • 1
    • Processor Socket
    • Socket H4 LGA-1151
    • Processor Supported
    • Core i7
    • Core i3
    • Core i5
    • Celeron
    • Pentium
  • Memory
    • Number of Memory Slots
    • 2
    • Memory Form Factor
    • UDIMM
    • DIMM
    • Maximum Memory Supported
    • 32 GB
    • Memory Technology
    • DDR4 SDRAM
    • Memory Speed Supported
    • 2666 MHz
    • 2400 MHz
    • 2133 MHz
  • I/O Controller
    • Controller Type
    • Serial ATA/600
  • Video
    • Onboard Video
    • CPU Dependent Video
  • Audio
    • Audio Channels
    • 7.1
  • Network & Communication
    • Bluetooth
    • Yes
    • Gigabit Ethernet
    • Yes
    • Wireless LAN
    • Yes
  • I/O Expansions
    • Total Number of Expansion Slots
    • 1.0
    • Total Number of PCI Express Slots
    • 1
    • Number of PCI Express x16 Slots
    • 1
  • Interfaces/Ports
    • Total Number of USB Ports
    • 4
    • Number of USB 3.1 Ports
    • 2
    • HDMI
    • Yes
    • DisplayPort
    • Yes
    • DVI
    • Yes
  • Onboard Interfaces
    • Number of SATA Interfaces
    • 4
    • Number of M.2 Interfaces
    • 1
    • Total Number of Onboard USB Ports
    • 4
    • Number of Onboard USB 3.1 Ports
    • 2
  • Physical Characteristics
    • Form Factor
    • Mini ITX
    • Width
    • 170.2 mm
    • Depth
    • 170.2 mm
  • Miscellaneous
    • Package Contents
      • H310M-ITX/ac Desktop Motherboard
      • Quick Installation Guide
      • I/O Shield
      • 2 x SATA Data Cables
      • 2 x ASRock WiFi 2.4/5 GHz Antennas
      • 1 x Screw for M.2 Socket
      • Support CD:
        • Drivers
        • Utilities
        • AntiVirus Software (Trial Version)
        • Google Chrome Browser and Toolbar
    • Country of Origin
    • China
    • Environmentally Friendly
    • Yes
    • Energy Efficiency Compliance
    • Energy-related Products Directive Ready (ErP Ready)
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
    • China Restriction of Hazardous Substances (China RoHS)
